Signal System
This signal system is a multi-level hoist signal device that uses a programmable controller for signal processing and transmission. The system consists of: a signal station at the wellhead and a signal station for each intermediate section downhole. Each section is centrally controlled by the PLC at the wellhead signal station, and only - a DP bus communication is required between each middle section to realize signal contact.
Cagories：
Keywords：
Signal System
Hotline：
Signal System
System Introduction:
This signal system is a multi-level hoist signal device that uses a programmable controller for signal processing and transmission. The system consists of: a signal station at the wellhead and a signal station for each intermediate section downhole. Each section is centrally controlled by the PLC at the wellhead signal station, and only - a DP bus communication is required between each middle section to realize signal contact.
| System Features: 1、Simple structure: connected by distributed PROFIBUS- _DP bus, less connection cable. 2、Reliable working:The device provides the relevant working mode and working execution signal to the multi-level hoist to ensure the correct operation of the hoist. 3、The hoisting system has increased the function of automatic control. 4、With "memory" function: it can "remember" the signals sent from the ground and the underground sections, including various maintenance signals. 5. Variable control program, with good flexibility: for the phased operation of the mining enterprises, this is very important, because after the change of process conditions in the underground section, etc., do not need to change the hardware of the signal system, only modify the original program to meet the new requirements. |
 |
